2 Mag MAXdrive with external control

Designed for chemical and biotechnical applications of all kinds as e.g. within the field of quality insurance and pilot plant stations, developed for highest demands, unbeaten strong, high stability as well as for uncompromising continuous operation.
Unbeaten strong magnetic stirrer with large set-up area, up to 250 litres stirring volume, also suitable for highly viscous media, very strong magnetic coupling by SmCo magnets, therefore predestined for magnetic power transmission over wide distances (up to 60 mm), for thick vessel bottoms or for double-coat vessels, ideal for the integration into process engineering systems.
Maintenance-free 2mag-motor-drive with large speed range from 100 up to 1,200 rpm.
Fully encapsulated and tight stainless steel housing, IP65, extremely robust construction and performance, easy to clean under running water and maximum firm.
Individual measurements on request.
3 years warranty on material- and manufacturing, developed and made in Germany.
Please order control unit MAXcontrol separately!

Stirring point: 1.
Stirring volume: 1 – 250 liters.
Speed range: 100 – 1,200 rpm.
Housing material: Stainless-steel.
Measurements (WxDxH): 260 x 260 x 68 mm.
Weight: approx. 9.0 kg.
Permitted operation conditions: -10 up to +50°C (at 95% humidity).
Permitted storage conditions: -40°C up to +70°C, 10 – 95%, 500 - 1060 hPa.
Protection category: IP 64.
Electrical data: 48 VDC
