2 Mag MAXcontrol
Control unit for the connection of MAXdrive, powerful 40 watts stirring power, large speed range from 100 up to 1,200 rpm.
Control unit for the connection of MAXdrive, powerful 40 watts stirring power, large speed range from 100 up to 1,200 rpm, variable SoftStart-function for reliable catching/centering and safe accelerating of the stirring bar at different volume and viscosities.
Digital display for speed- and SoftStart-setting (variable, 10-60 seconds), QuickSet for quick setting of the start-and maximum speed, QuickStop-function against after-run and glass breakage, storage of last function status when turning off, fi rm stainless steel housing, easy to clean.
3 years warranty on material- and manufacturing, developed and made in Germany.
Speed range: 100 – 1,200 rpm.
Stirring power (max.): 40W.
Acceleration: variable, 10-60 sec.
Housing material: Stainless-steel.
Measurements (WxDxH): 200 x 175 x 48 mm.
Weight approx.: approx. 1.8 kg.
Permitted operation conditions: 0 up to +40°C (at 80% humidity).
Permitted storage conditions.: -40°C up to +70°C, 10 – 95%, 500 - 1060 hPa.
Protection category: IP 20.
Electrical data: 100-240 V/50-60 Hz/1.5 A.
Iso Code | PCE |
---|---|
Manufacturer reference | 94400 |
UNSPSC code | 41103806 |
ISO code | PCE |
eclass | 32010000 |
leadtime | 12 |
Brand | 2 Mag |
Speed/frequency | 100-1200 rpm |
Sales Unit | Piece |
Power supply | 230V |
Overall dimensions | 200x175x48 mm(BxDxH) |
With display | Yes |
Warranty | 3 years |
Reference | A27805 |
Weight | 1,8 kg |
Control | External control unit |
With heating function | No |
