Macro cuvette quartz 100 - QS - path - 2 mm - 700 µl
Reference
A45800
Sales Unit
1 Piece
This high-precision macro quartz cuvette provides the utmost accuracy in terms of path length and parallelism and and outstanding measurement reproducibility. They can be used in spectroscopy and cytometry. The function-optimized design with beveled edges and corners protects against the risk of damage caused by splitting and assists users in their daily work
- Volume: 700 µl
- Optical path length: 2 mm
- Wavelength range: UV/VIS 200 - 2500 nm
- Surface flatness of 1 µm
- Measuring method: absorption cells
- Thanks to their stability, maximum precision and reliability when used for absorbance and fluorescence measurements, Hellma cuvettes work exceptionally well in a wide range of areas in the lab
- Extremely high parallelism of the windows with amaximum tolerance of ± 0.01 mm
- Exceptional optical path length accuracy down to0.003 mm (3 μm) for high dimensional accuracy and reproducible measurements results
- Unique surface flatness of the optical windows of0.001 mm (1 μm)
- With glass lid
- Very high temperature stability and chemical resistance due to thermal bonding of individualcomponents (effectively monolithic)
- Guaranteed transmission of at least 85% from200 nm to 3500 nm depending on the material
- Material colour code: QS, quartz glass
- Outside dimensions: 45 mm x 12,5 mm x 5,5 mm (h x w x d)
- Inside width: 9,5 mm
- Base thickness: 1,5 mm
- Center height: 8,5 - 20 mm
- Number of windows 2
| UNSPSC code | 41000000 |
|---|---|
| Manufacturer reference | 100-2-40 |
| eclass | 3203000 |
| Brand | Hellma |
| ISO code | PK |
| Sales Unit | 1 Piece |
| Center height | 8,5 mm |
| Color | transparent |
| Material | Glass |
| Reference | A45800 |
No price available or do you need more info for this product? Request your info with the form below.
