2Mag cuvetteMIXdrive 1 with external control
Miniaturized, wear-free magnetic stirrer with 1 stirring position for cuvettes.
Miniaturized, wear-free magnetic stirrer with 1 stirring position for cuvettes, optimized for stirring volume up to 25 ml, ideal size for system integration e.g. in photometer.
1 stirring position, 100% maintenance-free and wear-free by inductive 2mag-Magnetic-Drive concept for reliable mixing of solutions, jerk-free stirring even at low speeds.
Fully encapsulated and hermetically sealed stainless steel housing, IP68, water-, dust- and germproof, extremely robust construction and performance, easy to clean and maximum resistance, submersible in water- resp. oil baths, suitable for the use in CO2-incubators and ovens.
3 years warranty on material- and manufacturing, developed and made in Germany.
Please order the control unit MIXcontrol cleanroom separately.
Stirring points: 1.
Stirring volume / stirring point: 1 - 25 ml.
Stirring power (max.): 10W.
Material housing: PUR.
Material Sealing: PUR.
Permitted operation conditions: -10 up to +50°C (at 100% humidity, submersed).
Dimensions (WxDxH): 13 x 13 x 6 mm.
Weight (gross): approx. 0,1 kg.
Permitted storage conditions: -40 °C up to +70 °C, 10 – 95 %, 500 - 1060 hPa.
Operating voltage: 48 VDC.
Protection category: IP 68.
Iso Code | PCE |
---|---|
Manufacturer reference | 40400 |
UNSPSC code | 41103806 |
ISO code | PCE |
eclass | 32010000 |
leadtime | 12 |
Brand | 2 Mag |
Sales Unit | Piece |
Power supply | 48 VDC |
Overall dimensions | 13x13x6 mm(BxDxH) |
With display | No |
Warranty | 3 years |
Reference | A27777 |
Weight | 0,1 kg |
# stirring points | 1 |
Max. volume | 1-25 ml |
Control | External control unit |
With heating function | No |
